产品详情

货号(不锈钢)          I货号(碳钢)    测量范围(mm) )     读数值(mm)   A(mm)        B(mm)    C(mm)   D(mm)    H(mm)

153-525S               153-525C         0-200                    0.05              60             10          10             17           22

153-535S               153-535C         0-300                    0.05              60             10          10            17           22

153-550S               153-550C         0-500                    0.05         100/125/150  10          12      25/25/25    40/40/40 153-555S               153-555C         0-600                    0.05          100/125/150 10          12      25/25/25    40/40/40 153-560S               153-560C         0-800                    0.05          125/150/200  20          20     32/32/32    47/47/47 153-565S               153-565C         0-1000                  0.05          125/150/200  20          20      32/32/32    47/47/47 153-570S               153-570C         0-1500                  0.05          125/150/200  20/30     20      32/48/48   47/54.5/54.5 153-575S               153-575C         0-2000                  0.05          150/200/300  20/30     20      48/48/48    54/54/54 153-125S               153-125C         0-200                    0.02            60                10          10          17            22

153-135S               153-135C         0-300                    0.02            60                10          10          17            22

153-150S               153-150C         0-500                    0.02      100/125/150      10          12       25/25/25    40/40/40 153-155S               153-155C         0-600                    0.02      100/125/150      10          12        25/25/25   40/40/40 153-160S               153-160C         0-800                    0.02      125/150/200      20          20        32/32/32   47/47/47 153-165S               153-165C         0-1000                  0.02      125/150/200      20          20        32/32/32   47/47/47 153-170S               153-170C         0-1500                  0.02      125/150/200     20/30      20        32/48/48  47/54.5/54.5 153-175S               153-175C         0-2000                  0.02      150/200/300     20/30      20        48/48/48    54/54/54 153-625S               153-625C         0-200                    0.05/1/128" 60                10         10           17               22

153-635S               153-635C         0-300                    0.05/1/128" 60                10         10           17               22

153-650S               153-650C         0-500                    0.05/1/128" 100/125/150 10        12          25/25/25   40/40/40 153-655S               153-655C         0-600                    0.05/1/128" 100/125/150 10        12          25/25/25   40/40/40 153-660S               153-660C         0-800                    0.05/1/128" 125/150/200 20        20          32/32/32    47/47/47 153-665S               153-665C         0-1000                  0.05/1/128" 125/150/200 20        20          32/32/32    47/47/47 153-670S               153-670C         0-1500                  0.05/1/128" 125/150/200 20/30   20         32/48/48  47/54.5/54.5 153-675S               153-675C         0-2000                  0.05/1/128" 150/200/300 20/30   20         48/48/48   54/54/54 153-225S               153-225C         0-200                    0.02/0.001"   60               10       10           17                   22

153-235S               153-235C         0-300                    0.02/0.001"   60               10       10           17                   22

153-250S               153-250C         0-500                    0.02/0.001" 100/125/150 10       12         25/25/25       40/40/40 153-255S               153-255C         0-600                    0.02/0.001" 100/125/150 10       12         25/25/25       40/40/40 153-260S               153-260C         0-800                    0.02/0.001" 125/150/200 20        20        32/32/32       47/47/47 153-265S               153-265C         0-1000                  0.02/0.001" 125/150/200 20        20        32/32/32       47/47/47 153-270S               153-270C         0-1500                  0.02/0.001" 125/150/200 20/30   20         32/48/48  47/54.5/54.5 153-275S               153-275C         0-2000                  0.02/0.001" 150/200/300 20/30   20          48/48/48     54/54/54
